High Speed 6000BPH Glass Bottle Cleaning Washing and Drying Machine for Juice Beer Wine Production Line

Product Application

• This machine is a continuous soaking spray-punching full-automatic bottle washing machine. The inlet and outlet bottles are at the same end. The structure is compact and the occupied area is small. Only one person is required to operate the machine, thus saving labor cost, low water and steam consumption and convenient maintenance.
• The fuselage box body is welded by 8mm thick steel plates in sections. The weight of the equipment is supported by jack screws (height 200mm), and the height adjustable range is 50mm.
• The inlet and outlet bottles are layered up and down and in different directions, which can realize the separation of dirty and clean bottles and reduce the pollution of clean bottles.
• The bottle feeding and conveying device adopts a multi-rail buffer table, which can reduce the pressure between bottles to facilitate stable bottle feeding and reduce noise.

According to the single-end principle, the bottle push-in and push-out are completed on the same side, and the whole machine can only be operated by one person, which saves manpower, is convenient to maintain, and has the highest biosafety. The pre-cleaning device heats the bottle and removes coarse dirt. Then, each bottle stands on a horizontal loop track and passes through the lye soaking tank, the hot water tank and the warm water tank in order to completely wash away the dirt. Before the bottle leaves the machine again, it will be cooled by a small amount of fresh water in the post-treatment area, and the final residual dirt and lye will be removed

With over 20 years of industry experience, we have established ourselves as a leading provider of beverage production line solutions worldwide. Our state-of-the-art manufacturing facility spans over 50,000 square meters and is equipped with advanced machinery and technology.

We pride ourselves on our commitment to quality, innovation, and customer satisfaction. Our team of experienced engineers and technicians work closely with clients to understand their specific needs and deliver customized solutions that exceed expectations.

Q1: Are you a trading company or a manufacturer?
A1: We are a manufacturer, we supply the factory price with good quality,our Engineer Team with over 20 year's experience,welcome to visit!
Q2.How can I know your machine has good quality?
A2:We will send the video of testing the machine working condition for you before delivery,so you can send us your bottle samples for a trial.
Q3:What's your guarantee or the warranty of the quality if we buy your machines?
A3: We offer you high quality machines with 15 months guarantee and supply life-long technical support.
Q4: When can I get my machine after I paid?
A4: The delivery time is based on the exact machine you confirmed.
Q5: How can I install my machine when it arrives?
A5: We will send our engineers to your factory to install the machines and train your staff how to operate the machines.
Q6: How about the spare parts?
A6: After we deal down all the things, we will offer you a spare parts list for your reference.
Q7: How to join EQS and become an agent?
A7: We sincerely invite you to become our filling machine agent and jointly expand the market. By contacting us, submitting company information for qualification evaluation, and ultimately signing an agency agreement, you will receive comprehensive product training and market support.
